Key features
High-level product advantages presented in a cleaner review format.
Pre-configured with MUTCD-compliant WW+S
flash pattern for standard activation
Out-of-the-box connectivity
with MX Cloud™ and MX Field App™
Remote alerts
via email and text for knockdowns, battery status, and more
Real-time system access
for health status, GPS location, and activation logs
Solar-powered
and right-sized through project-specific Solar Power Reports (SPR); AC versions also available (MX 300/400 only)
Weatherproof aluminum housing
with vandal-resistant antennas
Compliant with MUTCD, SAE J595, and SAE J578
for industry-standard operation
Modular design options
for RRFBs, LED signs, and beacons with various mounting styles
Wireless synchronization
between systems up to 1,000 ft
Supports audible push buttons
, overhead lighting, and passive pedestrian detection
3-year limited warranty
with North American-based support
Specifications
Dedicated technical preview for quick review.
- Solar power
- 12 VDC operation, solar sized to specific geographic location; includes 12-month Solar Power Report
- Batteries
- Replaceable, recyclable, sealed, maintenance-free AGM batteries; system designed for 5+ year battery life
- AC power (MX 300/400 only)
- 100-240 VAC in standard configurations
- Enclosure
- Weatherproof, gasketed enclosure with vents for ambient air transfer (NEMA 3R); lockable door; cabinet systems include Type II lock option (standard for MX 400)
- Construction
- Corrosion-resistant aluminum with stainless steel hardware; raw aluminum finish or black powder-coated
- MX RRFB module
- Meets 11th Ed. MUTCD (Chapter 4L) and MUTCD (Canada) Standards; purpose-built optics exceed SAE J595 class 1 intensity by 2.5-3x when used as recommended and meet SAE J578 chromaticity; 3" (76 mm) x 7" (178 mm) clear, UV-rated polycarbonate lens with yellow LEDs and side-emitting pedestrian confirmation LEDs; yellow or black powder-coated light bar covers; uni-directional or bi-directional; RRFB backplate and mast arm mount available
- MX Beacon module
- Configurable to MUTCD 11th Ed. (Chapter 4S) Standard; 12" (305 mm) or 8" (203 mm) diameter LED modules, yellow; yellow or black heads in UV-resistant polycarbonate or aluminum
- MX LED sign module
- Meets MUTCD 11th Ed. (Chapter 2A.12) Standards; 3M High Intensity Prismatic or Diamond Grade retroreflective sheeting; standard 30" and 36" W11-2 and S1-1 sign sizes (others available); standard yellow and fluorescent yellow-green sign colours
- MX 100
- Integrated solar + battery; 12.6 x 13.6 x 5.3" (320 x 345 x 135 mm); 5 lb (2.3 kg) without batteries; 1-2x 7 Ah batteries; 15 W solar
- MX 200 (30 W)
- Integrated solar + battery; 18.3 x 15.7 x 5.8" (465 x 399 x 147 mm); 11 lb (5.0 kg) without batteries; 1-2x 18 Ah batteries; 30 W solar
- MX 200 (50 W)
- Integrated solar + battery; 18.3 x 26.3 x 5.8" (465 x 668 x 147 mm); 14 lb (6.4 kg) without batteries; 1-2x 18 Ah batteries; 50 W solar
- MX 300
- Separate solar + cabinet; 16.7 x 11.3 x 7.0" (424 x 287 x 178 mm); 10 lb (4.5 kg), AC version 12 lb (5.4 kg), without batteries; 1x 18, 35 or 55 Ah battery; 50, 80 or 170 W solar
- MX 400
- Separate solar + cabinet; 21.9 x 16.1 x 8.3" (556 x 409 x 211 mm); 19 lb (8.6 kg), AC version 21 lb (9.5 kg), without batteries; 1x 35, 55 or 100 Ah battery; 50, 80 or 170 W solar
- Solar panels (MX 300/400)
- 50 W: 26.3 x 21.2" (668 x 538 mm), 10 lb (4.5 kg); 80 W: 30.7 x 26.5" (780 x 672 mm), 13 lb (5.9 kg); 170 W: 59.1 x 26.3" (1500 x 668 mm), 25 lb (11.3 kg)
- Options
- Audible Information Device (AID) push button, overhead lighting fixture, passive pedestrian detection
- Mounting (MX 100/200)
- Top of pole or side of pole; universal solar mounts for 2-2.5" perforated square posts, 2.38-2.88" OD round poles and 3.5-4.5" OD round poles
- Mounting (MX 300/400)
- Cabinet mounts: standard banding, through bolts, U-bolts (MX 400 only); universal solar mounts: 3.5-4.5" OD round poles, side of pole
- Local communication
- MX Field App (Bluetooth)
- System-to-system
- Linked MX systems flash in sync up to 1,000 ft (305 m) away
- Remote communication
- MX Cloud (cellular)
- Location and time
- GPS
- MX subscription
- 3 years out-of-the-box remote connectivity with MX Lite
- MX Cloud
- Remote health status monitoring, email/SMS alerts, scheduling, asset management, programming and more
- MX Field App
- Bluetooth mobile app for on-site setup, local access to default settings, system health status and more
- Default flash pattern
- Wig-wag plus simultaneous (WW+S)
- Warranty
- 3-year limited warranty on MX system; 1-year limited warranty on batteries
